- LIGHTWEIGHT AND ROBUST ALUMINIUM FRAME & CARBON FORK WITH INTEGRATED C.I.S. CABLE ROUTING, PLUS MOUNTING POINTS FOR EVERYTHING YOU NEED
- SHIMANO GRX400 2X10 GROUPSET WITH SPECIAL GRAVEL ERGONOMICS FOR STABLE AND DEPENDABLE SHIFTING ON ANY TERRAIN
- RELIABLE STABILITY AND LONG-LASTING QUALITY: DOUBLE-SEALED NOVATEC ROAD BOOST HUBS AND 23 MM WIDE WTB RIMS
Pushes Boundaries
COMFORT AND CONTROL ON ANY TERRAIN
Whether bad weather, demanding surface, steep climbs or long distances – the robust and comfortable gravel bike offers full control thanks to an adapted frame geometry, wide handlebars with flare and disc brakes. The clean cockpit with C.I.S. cable routing from the handlebar directly into the headset avoids any hustle when installing a handlebar bag. To climb every mountain even with equipment, the Shimano GRX gravel groupset comes with a pleasant transmission ratio for everyone.
HUGE TYRE CLEARANCE
The ATLAS comes with 700c tyres and can take tyre widths up to 47 mm, but is also 650b-ready with tyre clearance up to 51 mm. Therefore, you have plenty of opportunities to spec your ATLAS appropriate to your next adventure. Furthermore, the Road Boost technology provides high stability due to better spoke tension and bigger tyre clearance while still having short chainstays. No matter the objective, the ATLAS fully supports your ride – even to the end of the world.
VARIOUS OPTIONS TO MOUNT EQUIPMENT
Five bottle cages can be mounted: On the seat tube, above the down tube, underneath the down tube and on each side of the fork. The position of the bottle cage above the down tube is adjustable to fit a frame bag. Additionally, it is possible to equip the ATLAS with various features thanks to many mounting options on the aluminium frame and carbon fork. The mounting points on the fork are approved for 3 kg each side and can also be used for carrying any other equipment.
| FRAME |
Aluminium, disc, BSA, 148x12 mm thru axle, flat mount 160/160 mm, internal cable routing |
| FRAME MATERIAL |
Aluminium |
| FORK |
Carbon, disc, 110x12 mm thru axle, flat mount 160/160 mm, internal brake cable routing, multiple mounting points |
| SHIFTER |
Shimano GRX ST-RX400, 10-speed |
| FRONT DERAILLEUR |
Shimano GRX FD-RX400 |
| REAR DERAILLEUR |
Shimano GRX RD-RX400, 10-speed |
| SPROCKET |
Shimano CS-HG5010, 10-speed |
| CHAIN |
Shimano Tiagra CN-4601, 10-speed |
| CRANKSET |
Shimano GRX FC-RX600, 10-speed |
| BOTTOM BRACKET |
BSA |
| TRANSMISSION OF DRIVE |
Front: 46/30T, Rear: 11-36T |
| HANDLEBAR |
FOCUS JD RA85, 31,8 mm, drop: 116 mm, reach: 74 mm, flare: 10° |
| STEM |
Aluminium, 31,8 mm, 6° |
| HEADSET |
ACROS IS 52/286-IS52/40 (ICR), FOCUS integrated C.I.S. |
| SADDLE |
WTB SL8 |
| SEATPOST |
Aluminium, 27.2 mm, 0 mm set-back |
| BRAKES |
Shimano GRX ST-RX400 + BR-RX400 |
| BRAKE LEVER |
Shimano GRX BL-RX400, 10-speed |
| BRAKE |
Disc |
| RIMS |
WTB ST i23 TCS, tubeless ready |
| REAR HUB |
Novatec D982TSB, 12x148 mm |
| FRONT HUB |
Novatec D041, 12x110 mm |
| TIRES |
WTB Riddler, 700 x 45C |
| GEARS |
20 |
| BIKE WEIGHT |
11.30 kg |
| SIZE |
XS, S, M, L, XL |
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
